Overview

UL-142 tanks are steel atmospheric tanks intended for aboveground storage of non-corrosive, stable, flammable, and combustible liquids. Maximum allowable working pressure is 0.5 psig as measured from top of tank.

Horizontal Configurations

Tanks can be furnished with stationary support saddles, anti roll supports or structural skids. Only new steel materials are used in tank constructions.

Each tank is sized with the appropriate normal and emergency vent openings as defined in the tank's standard of construction. Horizontal tanks may be single or double wall construction. If the tank is a double wall configuration, then it has interstitial monitoring capabilities. Tanks may also be built with or without multiple compartments for multiple fuel storage. Tanks are built to Underwriters Laboratories specification standard UL-142.

Vertical Configurations

Vertical tanks may be of single or double wall construction. If the tank is a double wall configuration, then it has interstitial monitoring capabilities. These tanks may also be built with or without multiple compartments for multiple fuel storage. Tanks generally have flat bottoms and conical roofs.

Special fabrication can incorporate dished tops, dished and coned bottoms all supported on skirts or legs. Only new materials are used in tank construction. Each tank is sized with the appropriate normal and emergency vent openings as defined in the tank's standard of construction. Tanks are built to Underwriters Laboratories specification standard UL-142. For special applications, such as products that have a larger specific gravity than water, Modern offers American Petroleum Institute, API, designed tanks in the API-620 or API-650 design configurations.

Rectangular Configurations

Rectangular tanks may be of single or double wall construction. If the tank is a double wall configuration, then it has interstitial monitoring capabilities. Modern is the only manufacturer in the world licensed to build a shop-fabricated UL-142 rectangular tank with a height greater than 103 inches up to 168 inches and infinite length.

Diked Tanks

Diked containments can either be open top or closed top construction. Each tank is sized with the appropriate normal and emergency vent openings as defined in the tank's standard of construction.

The primary containment aboveground storage tank is housed within a rectangular steel dike which contains the product should a spill, tank leak or rupture occur. Tanks are built to Underwriters Laboratories specification standard UL-142.



Features

  • Horizontal Storage: 300 to 50,000 gallon capacity also available in rectangular constructions up to 24,000 gallons
  • Vertical Storage: 500 to 50,000 gallon capacity
  • Rectangular Storage: Up to a maximum height of 14 feet and infinite length.
  • Horizontal Diked: 300 to 20,000 gallon capacity
  • Material of construction may be carbon or stainless steel
  • Underwriters Laboratories Construction, UL-142
  • Single or double wall steel tank configurations available
  • Available with multiple compartments for multiple fuel storage
  • Compatible with gasoline, diesel, fuel oil, ethanol, methanol and additives
  • Lined internally for special applications, such as jet fuel or potable water storage
  • Tanks available with pump platforms and accessories
  • Fuel dispensing equipment available for Horizontal and Diked Storage Tanks
  • Special pumping equipment available for Vertical Storage Tanks
  • Tanks may be supported on stationary saddles, anti-roll stabilizers or structural skid configurations for Horizontal Storage Tanks or flat bottom, beam legs or skirt for Vertical Storage Tanks

Additional Options

Containment Dike
Internal Overflow Compartment
